MOLDED CABLE ASSEMBLIES WITH DIN PLUGS (continued)
247
STYLES RA300 AND ST300
PART NUMBERS – MOLDED CABLE ASSEMBLIES
SPECIFICATIONS
Term.
Term.
ELECTRICAL
Contact Resistance: Cord Plugs and Receptacles.
.010 ohms, contact spring/pin; .030 ohms, ground clip/shell.
Control and Switching Receptacles: .015 ohms,
Part Number
? 305KD084184
Description
Black coil cord. 15" (381 mm)
retracted; 78.74" (2 m)
extended. 5 pin male with
other end stripped and tinned
A
ST305
B
—
contact spring/pin; .020 ohms, switch contacts.
on cable number W-1301-2.
Dielectric Withstanding Voltage: 500 V (rms).
? 305HJ084184
Black cable cord. 7 feet (2.13 m)
ST305
—
Leakage Resistance: 10 5 M ?
MECHANICAL
in length. 5 pin male with
other end stripped and tinned
on cable number W-1279-2.
Life: 5000 cycles
? 306HK042306
Black cable cord. 39.37" (1 m)
ST306
ST306
Insertion/Withdrawal Forces:
Number of Insertion Force
Contacts pound/N
Withdrawal Force
pound/N
? 306HK084306
in length. 6 pin male to
6 pin male on cable number
W-1289-2.
Black cable cord. 78.74" (2 m)
ST306
ST306
2
3
4
5
6
7
3.6/(16)
5.4/(24)
7.2/(32)
9.0/(40)
10.8/(48)
12.6/(56)
.45–2.7/ (2–12)
.67–4.1/ (3–18)
.90–5.4/ (4–24)
1.24–6.8/ (5.5–30)
1.46–8.1/ (6.5–36)
1.68–9.5/ (7.5–42)
in length. 6 pin male to
6 pin male on cable number
W-1289-2.
? Special order only; contact Switchcraft.
FOIL SHIELD CABLES – STRAIGHT
8
14.4/(64)
1.90–10.8/ (8.5–48)
Part Number
Color
Length, inch (mm)
W-1279-2
W-1289-2
Black
Black
Length must be specified.
PLUG MATERIALS
Pin Contacts: Silver-plated, copper alloy.
Insulating Washer: Thermoplastic.
Locking Plug Housing: Nickel-plated, die-cast zinc alloy.
Other Housings: Plated steel.
Molded Handle: Flexible thermoplastic. Strain relief
matte finish.
NOTE: All connectors meet DIN specifications. Din
specification numbers (except for 4-pin, 5-pin 240°)
will be furnished on request.
ORDERING
1. See table below for termination descriptions. Termination
code is the same number as the plug style (e.g. termination
code for a ST305 is 305).
2. See page 251 for ordering guide.
Part Numbers-Male (pins)
3@180°
4@210°
5@180°
5@240°
6@240°
7@270°
8@270°
Pin Arrangements
B
D
F
E
G
H
N
Description
Straight handle.
ST303
ST309
ST305
ST304
ST306
ST307
ST308
Straight handle. 30° twist
lock ring fastening, mates with
ST323
ST329
ST325
ST324
ST326
ST327
ST328
lock flange plugs and receptacles.
Right-angle handle.
RA353
RA359
RA355
RA354
RA356
RA357
RA358
Right-angle handle. 30° twist
lock ring fastening, mates with
RA373
RA379
RA375
RA374
RA376
RA377
RA378
lock flange plugs and receptacles.
1. See next page for Pin/Contact arrangements.
DIMENSIONS ARE FOR REFERENCE ONLY
